90-315mm Butt fusion pipe welding machine - hydraulic
£3,054.00
In stock
Product Details
Brand:
Ramech
HB-315 90-315mm butt fusion welding machine for pipes: PE, HDPE, PP, PVDF with hydraulic clamp
Set includes:
- Sled with an oblique bed + removable transport wheels (LIGHT AND RIGID CONSTRUCTION)
- (2 fixed clamps, 2 adjustable, hydraulic clamp, set of reduction rings)
- Heating plate (top class Teflon coating)
- milling machine 350 rpm
- hydraulic unit with PRESSURE ACCUMULATOR
- stand for a milling machine, heating plate
- control panel: with a digital indicator of the current and set temperature, voltage, pressure, welding and cooling time indicator (indicators under the metal cover) + welding table.
- set of necessary tools (spanners, etc.)
The machine is calibrated, after zero inspection in our service centre, ready for operation
Specification:
Pipe diameters: 180-500mm (90, 110, 125, 140, 160, 180, 200, 225, 250, 280, 315)
Welded materials: PE, PP, PVDF, HDPE, PB, PPR
The power of the heating plate is 3100w
Milling machine power 1100W
Hydraulic pump power: 750W
Pump working pressure 0-8MPa
UK plug, set of spanners
This product comes from our warehouse in Poland and it is on 2 week lead time
90-315mm Butt fusion pipe welding machine - hydraulic
