Industrial RFID reader IND-CLD features following specification:
- fitted with lcd display,
- hermetic housing IP65
- modern PoE IEEE 802.3af power supply
- additional RS485 port,
- internal RTC clock with battery backup,
- built-in memory,
- supporting the popular tag standards – Unique, Mifare is a modern, multifunctional device that will work not only on industrial grounds.
COMMUNICATION
LAN and RS485 ports are used for communication. The inputs support the following protocols:
- HTTP server mode
- HTTP client mode
- SNMP
- Modbus TCP
- Modbus RTU
- and a built-in web server that allows communication via popular web browsers (Opera, Mozilla, Firefox, Chrome)
APPLICATION
Industry, services, trade, logistics are just some of the industries in which it is possible to use the reader.It can be used as a machine login tool, room access (storage), loyalty system component, work time recorder, etc. Using your own application or protocols supported by the reader the user has the ability to control practically every element of the reader – display, buzzer, inputs, outputs. Thanks to the built-in memory, it also has access to the list of logs stored in it.The logs may be available in the form of ID numbers of the tags or previously assigned names. It is possible to assign normal user status to specific tags (User) or with broader powers (Master).
TECHNICAL DATA
POWER
- Power supply voltage: 10-24VDC or PoE 802.3af or passive POE
- Power consumption: max 2,5W ( ~200mA@12V)
COMMUNICATION
- Ethernet
- RS485
TRANSPONDER AND MEMORY
- Tag reading distance: up to 8cm from the front of the device (LCD display side),
- Memory of the ID numbers: 1 000,
- Memory of the events: 30 000,
- Defining access hours for 4 groups of ID numbers,
- Assign names to ID numbers.
INPUTS
- 2 digital inputs
OUTPUTS
- 2 relay outputs
